DIGITAL RESEARCH PATHOLOGICAL MICROSCOPE RXL-Digi |
|
| Specification |
| Optical System |
Chromatism Reduction/ICS Infinite Correction. |
| Observation Head |
Binocular 30° Inclined, IPD 52-75mm, Anti Mould Design. |
| Eyepieces |
WF10x/18mm,WF16x/12mm, High Eye Point Eyepiece. |
| Objectives |
CRCS Semi-Plan 4x, 10x, 40x (Spring) And 100x (Spring, Oil). |
| Imaging Device |
Built-In 1/3" Colour Digital CCD High Resolution Camera. |
| Nosepiece |
Reversed Quadruple Revolving Nosepiece with Positive Click Stops. |
| Stage |
Low Co-Axial Mechanical Stage 142mm X 132mm With Movement 70mm X 50mm. |
| Focussing |
Tension Adjustable Co-Axial Coarse & Fine with Shuttle Control. |
| Condenser |
Centrable Abbe Condenser N.A. 1.25 with Diaphragm & Filter Holder. |
| Illuminator |
Koehler with Halogen Lamp 12V-20W & Continuos Adjustment. |
| Power Source |
110/220 Volts Variable Voltage with BIS & CE Standards. |
|
| |
 |
DIGITAL STEREO ZOOM MICROSCOPE RSM-Digi |
|
| Specification |
| Optical System |
Par Focal Flat Field Continuous Zoom. |
| Observatin Head |
Binocular 45° inclined IPD 52-75mm with anti mould. |
| Eyepieces |
Focusable WF 10X/22mm, WF15X/16mm, High point design. |
| Objectives |
Flat Field 1:4 Zoom with continuous zoom |
| Imaging Device |
Built-in 1/3" Color CCD High Resolution Camera |
| Magnification |
10x to 60x with WF 10x and WF 15x |
| Working Distance |
100mm with pay load of 2 Kgs. approx. |
| Resolution |
720x576 pixels (PAL), 720x480 pixels (NTSC) |
| Focussing |
Rack and Pinion with tension knobs on rigid stand |
| Light Sensitivity |
>= 0.8 Lux F 1.2 5600 ° K. |
| Incident Illumination |
12V/20W. |
| Transmitted Illumination |
12V/10W. |
| Power Source |
110V/220V with CE Standards. |
|
| |
|
DIGITAL LIQUID CRYSTAL MICROSCOPE RDMS-100 |
|
| Standard Function |
| 1. |
3.14 MEGA pixels. Show in real time, function for photo taking and video capture. |
| 2. |
Reticle customize, Convenient to orientation and go on simple measurement to observe, can choose the line type and color. |
| 3. |
8.4 TFT LCD display. |
| 4. |
Built-in min. 8 MB MMC memory card |
| 5. |
Support high-capacity memory card; SD/MMC, the maximum 512 MB. |
| 6. |
Photo playback, 4x digital zooming. |
| 7. |
AV output, Show in step |
| 8. |
Time mark in step |
| 9. |
Video recording and video re-playing function. |
| 10. |
Multi-function LED illuminating system. |
|
| |
|
|
|
