| PORTABLE METALLURGICAL MICROSCOPE WITH CHARGEABLE BATTERY RMM-5 |
|
| Specification |
| Eyepiece |
WF 10X (High Eye - Point), Micrometer eyepiece WF 10X with calibration slide 1/100mm. |
| Objectives |
M4X, M10X, M20X & M40X. |
| Standard Magnification |
40x & 400 |
| Illuminator |
6V/3Watt., incident lightthrough Epi-Illuminator with rechargeable battery pack etc. 110/220Volt AC. |
|
| |
 |
| LABORATORY METALLURGICAL MICROSCOPE RMM-6 |
|
Monocular inclinable body having coarse and graduated fine motion knobs, Incident light through epi-illuminator with iris diaphragm and slot for filters, equipped with triple revolving nose-piece, special graduated detachable mechanical stage for x-y movement of specimen, solid state variable light conrtol transformer 20 watt for Halogen Bulb. Supplied with a daylight blue filter in mount, a spare bulb, vinyl cover, complete in a plywood storing cabinet with following optical combination :
| Specification |
| Ach. Objectives |
M 10x and M 40x |
| Huy. Eyepieces |
10x and 15x
(i) With achromatic objectives.
(ii) With Achromatic objectives assembled from imported hard coated lenses for anti-reflection. |
|
| |
|
| MONOCULAR METALLURGICAL MICROSCOPE RXM-7 |
|
Rigid and stable body fitted with monocular observation tube, inclined at 45° Bright field, incident light through epi-illuminator with centring provision, iris diaphragm and a slot for dropping filters. It is having precise quadruple revolving nosepiece with positive click stop co-axial mechanical stage of x-y movement of specimens upto thickness 65mm. Built-in base transformer. Halogen Bulb 6V 20W controlled by a variable intensity control knob. Supplied with daylight blue filter, operating manual and vinyl cover in a sturdy plywood storing cabinet, with following optical combination.
| Specification |
| Ach. Objectives |
M5x, M 10x and M 40x (SL) |
| Huy. Eyepieces |
H6x and WF10x
(i) With achromatic objectives.
(ii) With Achromatic objectives assembled from imported hard coated lenses for anti-reflection. |
|
| |
|
| BINOCULAR METALLURGICAL MICROSCOPE RXM-7B |
|
Rigid and stable body fitted with Binocular observation tube, inclined at 45° Bright field incident light through epi-illuminator with centring provision, iris diaphragm and slot for dropping filters. It is having precise quadruple revolving nosepiece with positive click stops. Co-axial mechanical stage for x-y movement of specimens upto thickness 65mm. Built-in base transformer. Halogen Bulb 6V 20W controlled by variable intensity control knob. Supplied with day light blue and green filters in plastic mounts, operating manual and vinyl cover in a sturdy plywood storing cabinet with following optical combination.
| Optical Combination |
| Ach. Objectives |
M5x, M 10x and M 40x |
| Huy. Eyepieces |
H6x and WF10x
(i) With achromatic objectives.
(ii) With Achromatic objectives assembled from imported hard coated lenses for anti-reflection. |
|
| |
|
| TRINOCULAR METALLURGICAL MICROSCOPE RXM-7T |
|
Bright field, inclined light through epi-illuminator with centring provision, iris diaphragm and slot for filters. It is having precise quadruple revolving nose-piece with positive click stops, co-axial mechanical stage for x-y movement to permit specimens upto thickness 65mm. Built-in base transformer, Halogen Bulb 6V 20W controlled by a variable intensity control knob. Supplied with daylight blue and green filters in plastic mounts, a spare blub & vinyl cover in a sturdy plywood storing cabinet with the following optical combination.
| Optical Combination |
| Ach. Objectives |
M5x, M 10x and M 40x (SL) |
| Huy. Eyepieces |
H6x and WF10x (Paired) & P 7x.
(i) With achromatic objectives.
(ii) With Achromatic objectives assembled from imported hard coated lenses for anti-reflection. |
|
| |
|
| UNIVERSAL TRINOCULAR METALLURGICAL MICROSCOPE RMM-8T |
|
Produces clear, sharp and brightfield images of prepared metal samples and other specimens. Standard magnification is 40x to 600x, which can be further increased up to 2000x with optional objectives and eyepieces. DIN Size coated optics are offered as standard equipment.
Trinocular observation head consists of adjustment for interpupillary distance, dioptic focussing and a lever for diverting light from Binocular Head to Photo-Tube. A common built-in transformer provides two illumination systems, 6V-20W, for vertical & transmitted light. Koehler's type vertical illuminator provides ample reflected light for all visual, photo & camera requirements, at all magnifications, is fitted with filter slot, aperture & field diaphragms. Transmitted light illuminator is provided with sub-stage condenser for background lighting of holes, pits and translucent objects. Coaxial coarse & fine focus control knobs move the stage and low-positioned co-axial mechanical stage knobs are adjacently placed for convenient control.
| Standard Optical Combination |
| Achromatic Flat Field DIN Objectives |
M4x, M10x and M40x. |
| Widefield Eyepieces |
WF 10x and WF 15x (Paired) and P7x Eyepiece. |
|
| |
|
| MONOCULAR METALLURGICAL MICROSCOPERMM-55 |
|
| Specification |
| Observation Head |
Monocular Observation Head inclined at 45-degrees. |
| Nosepiece |
Quadruple revolving Nosepiece. |
| Objectives |
M4X, M10X, M20X and M40X specially corrected for flatfield achromat. |
| Eyepieces |
WF 10X and H5X. |
| Magnification |
100x to 600x. |
| Illuminator |
Brightfield vertical illuminator 6V-20W Halogen with aperture diaphragm, filter slots and bulb centring mechanism. |
|
| |
|
| BINOCULAR METALLURGICAL MICROSCOPE RMM-55B |
|
Specification As per Model RMM-55 but supplied with Binocular observation Head. |
| |
|
| TRINOCULAR METALLURGICAL MICROSCOPE RMM-55T |
|
Specification As per Model RMM-55 but supplied with Trinocular observation Head. |
| |
|
| IM-1 Heavy Base with co-axial mechanical stage for x-y movement for above. |
|
IM-1 Heavy Base with co-axial mechanical stage for x-y movement for above. |
| |
|
| INVERTED METALLURGICAL MICROSCOPE RMM-77 |
|
A latest Binocular inverted Metallurgical Microscope equipped with vertical illuminator having centring provision, field and aperture, diaphragm and slot for dropping filters, built-in base, variable solid state transformer, large sturdy stage with co-axial arrangement for x-y axis movements, coarse and fine graduated focussing knobs. Supplied with two coloured filters in metal mount, Rexine cover, wooden base stand with drawer and following optical combination.
| Optical Combination |
| Eyepieces |
WF 10x (Paired). |
| Objectives |
M 5x, M 10x, M 20x and M 40x (SL). |
|
| |
|
| INVERTED METALLURGICAL MICROSCOPE (BINOCULAR) RMM-88 |
|
It has been engineererd to meet the requirements of the modern metallurgical laboratory. The optics system has been designed with great care to guarantee full contrast images, completely free from glare. Objectives are corrected, flat field achromats and having coating for anti-reflection.
A special mechanical stage, size 150x160 mm with low drive co-axial control of the inverted design. The transformer 12V, 50 watt is built in the base of Microscope.
| Specification |
| Magnification |
40x to 1000x Dry. |
| Objectives |
M 4x, M 10x, M 40x and M 50x (Dry) |
| Eye Pieces |
WF 10x and WF 20x |
Supplied complete in a storing cabinet with stage clips, 3 stage insert plates, green and blue filters, spare bulb, vinyl cover and operating manual. |
| |
|
| INVERTED METALLURGICAL MICROSCOPE RMM-1 |
|
Inverted metallurgical Microscope has been engineered to meet the requirements of modern metallurgicalc laboratories. The time - tested inverted design is most logical and practical solution for a metallurgical microscope. A special feature of the inverted design is flat unobstructed stage surface which places no limitation on the size & height of the specimen. Quality Assurance throughout the manufacturing ensures that compliance with demanding performance is strictly matched.
| Specification |
| Binocular Head |
Sidentopf designed having large prisms with inter pupillary and dioptric adjustments. |
| Objectives |
Achromatic flat field Metallurgical corrected and anti-mould fungus.
M4x (NA 0.12), M10x (NA 0.25), M20x (NA 0.40) and M40x (NA 0.65) |
| Eyepieces |
Wide field eyepieces HKW 10x and WF 20x (Paired) with eye guards. |
| Magnification |
From 40x to 800x standard magnification under visual observation. |
| Mechanical Stage |
Built-in graduated stage, size 165mm x 180mm, having 30mm x 30mm orthogonal movements, provided with low-positioned coaxial controls. |
| Focussing Controls |
Stage height is adjustable by handle in a range of 30mm. Graduated fine focus control is adjustable in a range of 2mm. |
| Illuminator |
Koehler's illuminator through built-in-base transformer, complete with field & aperture diaphragms filter slot & bulb-centering mechanism. |
| Polarizing Filters |
Having removable built-in rotatable analyzer & lamp polarizer filter to work in polarized light. |
| Photo-Mechanism |
Built-in optical path selector is incorporated for photomicrography. 4x photo-tube for 35mm camera, C-mount for CCD camera and adaptor for digital camera are optionally available. |
| Standard Accessories |
Large Stage Clip, 3 Stage Insert Plates opening 15mm, 25mm & graduated 25mm, Green, Blue and Polarizing Filters Vinyl Cover, Spare Bulb & Fuse, Wooden Storing Cabinet and Operating Instruction Manual. |
| Optional Accessories |
|
Austenite Grain Size Eyepiece |
This eyepiece is used with the 10x objective, fitted with a rotating turrent having eight standard ASTM and JIS grain size charts, which can be rotated to cover the entire field or adjacent charts. |
Filar Micrometer Eyepiece |
This eyepiece is used in linear measurement of micro size, planting thickness etc. Direct reading upto 0.001mm with the help of M10x objective. |
| |
35mm Camera Attachment, Digital Camera, CCD Camera, Stage Micrometer, Micrometer Eyepiece, Counting Reticles, Filters, Bulbs, Special Dry Objectives, Image Analyzer, etc. |
|
| |
|
| INVERTED METALLURGICAL MICROSCOPE RMM-2 |
|
| Specification |
| Viewing Head |
Sidentopf Trinocular head with dioptric and interpupillary adjustment from 48mm. to 75mm. |
| Magnification |
With Standard optics for dry magnification and visual observation from 40x to 600x. |
| Eyepieces |
High eye point, extra Widefield DIN EW 10x/20 and WF 15x/15 (paired) with eye guards. |
| Objectives |
Infinity Plan Achromatic DIN size flat field metallurgical corrected and anti-mould/fungus. M4x (N.A. 0.12), M 10x (N.A. 0.25), M20x (N.A. 0.40) and M40x (N.A. 0.56). |
| Mechanical Stage |
Plain stage size 160x250mm. attachment mechanical stage X-Y co-axial control moving range 120x78mm., auxilliary stage 70 x 80 mm. Orthogonal movements on precision ball bearing guides, provided with Low-positioned co-axial controls, vernier reading to 0.1mm. |
| Focussing |
Stage height is adjustable through co-axial low positioned coarse and fine focus controls, graduated to two microns per division, are fitted with tension adjustment and safety auto stop. The co-axial movements are on precision ball bearing hardened steel tracks for smooth long life. |
| Illuminator |
Koehler's illuminator 6V - 30W halogen through built-in base transformer, complete with field and aperture diaphragms, filter slots and bulb-centering mechanism are provided. |
| Polarizing Filters |
Built-in slots for Analyzer and Polarizer, to work under simple polarizing. |
| Size |
540mm. x 315mm. x 280mm. |
| Weight |
Net Weight - 14 Kgs. Gross Weight - 19kgs. |
| Standard Accessories |
Large Specimen clamps 3 round stage insert and plates opening 10mm., 15mm., 3 square plates for stage with aperture 10mm., 15mm. and 20mm. Four in mount, Analyzer and polarizer, Vinyl Dust Cover, Spare Bulb, Fuse, Operating Instructions etc. |
| Optional Accessories |
Stage Micrometer, Micrometer Eyepieces, filar Micrometer Eyepiece, Grain Size Eyepiece, Counting Reticles, Spare Objectives M60x, M100x (dry), Eyepieces WF 10x, 15x, 20x, etc. Automatic Image Analyzer, Digital Cameras, High Resolution CCD Cameras etc. |
|
| |
|
|
|
