| ROM-100 SHOP MICROSCOPE |
|
This microscope is a precision workshop instrument. The light source is adjustable on a swivel. The reticle can be focussed by moving the eye piece lens up or down. The object is focussed by rack and pinion movement. It is inexpensive substitute for Tool Maker's Microscope and are used where conventional tools like micrometer, dial gauges are ineffective. The measurements can be done with the microscope. The Microscope are available in 40x, 60x & 100x magnifications.
| Technical Specification |
| Model |
R-40 |
R-60 |
R-100 |
| Magnification |
40x |
60x |
100x |
| Work distance |
24 |
24 |
6.4 |
| Field of View |
4.25 |
3.25 |
1.7 |
| Least count |
0.02 |
0.02 |
0.01 |
* Dimensions given are in mm. |
| |
 |
| RBM-102 POCKET OPTICAL COMPARATOR |
|
Pocket Optical Comparator is made from clear acrylic cell which allows outside light to illuminate the object and accepts all glass reticles of 27 mm diameter. It is supplied with standard linear scale reticle in a carrying case. |
| |
|
| RBM-103 RADICAL ILLUMINATED OPTICAL COMPARATOR |
|
Radical Illuminated Optical Comaparator is a versatile device for rapid measurements of length, diameter, angles, threads, etc., and has its own light source. It is provided with two elements of 10x, aberration free magnifiers for convenience of observation. This can be focussed by spiral movement of eye piece. The light source consists of 2x 1.5 volt of standard no. 950 dry cells. A choice of ten reticles of 48.5 mm. diameter glass disc are available to suit various requirements. Any two reticles, as per choice, are supplied along with flash light comparator. Spare reticles can also be supplied at extra cost. |
| |
|
|
