| RSM-8 BINOCULAR STEREO ZOOM MICROSCOPE |
|
| Specification |
| Observation Head |
Binocular tube with an inclination of 45° for greater ease of observation. |
| Eyepieces |
Extra wide field eyepieces 10x (Paired). |
| Zooming Ratio |
6:4:1. |
| Magnification |
7x to 45x. (Standard) |
| Focussing |
Rack-Pinion focussing stroke 50mm. |
| Working Distance |
Standard Working distance 100mm, regardless of magnification. |
| Interpupillary Distance |
54 to 75mm. |
| Dioptric Adjustment |
Dioptric adjustment with a range of ±5 diopters is possible with both Oculars |
| |
|
Crisp, erect images with high resolution and excellent stereoscopic effect.
Binocular body can be rotated a full 360° and locked in any position desired.
Once brought in focus, image ramains clear and sharp throughout the whole zoom range.
Dual Illumination system having incident and transmitted illuminators, for individual use or both at a time controlled through solid state built-in transformer 6 Volts 20 Watts for halogen Bulbs.
Packed in plywood Storing cabinet with operation manual, vinyl cover etc. |
| |
 |
| RSM-8A BINOCULAR STEREO ZOOM MICROSCOPE |
| |
Stand is suitable for use in natural light or with optional external illuminators. |
| |
|
| RSM-88 BINOCULAR STEREO ZOOM MICROSCOPE |
| |
Transmitted & Incident lights are built in the stand. Long life and low temperature fluorescent lamps are provided for continuous observation. |
| |
|
RSM-8F BINOCULAR STEREO ZOOM MICROSCOPE |
|
Large stage is equipped for convenience of work. A long life and low temperature 10W Fluorescent lamp is provided for built in incident light. |
| |
|
| RSM-8DF BINOCULAR STEREO ZOOM MICROSCOPE |
|
Jewel Microscope is used to distinguish between genuine and imitation gems, to inspect surface inclusions, to judge production of origin and to inspect polishing. The Microscope is provided with transmitted and incident light system, darkfield attachment and a gem clamp. |
| |
|
| RSM-9 TRINOCULAR STEREO ZOOM MICROSCOPE |
|
| Specification |
| Observation Head |
Trinocular tube with an inclination of 45° for greater ease of observation. |
| Eyepieces |
Extra wide field eyepieces 10x (Paired), Photo Eyepiece WF10X. |
| Zooming Ratio |
6:4:1. |
| Magnification |
7x to 45x. (Standard) |
| Focussing |
Rack-Pinion focussing stroke 50mm. |
| Working Distance |
Standard Working distance 100mm, regardless of magnification. |
| Interpupillary Distance |
54 to 75mm. |
| Dioptric Adjustment |
Dioptric adjustment with a range of ±5 diopters is possible with both Oculars |
| |
|
Crisp, erect images with high resolution and excellent stereoscopic effect.
Trinocular body can be rotated a full 360° and locked in any position desired.
Once brought in focus, image remains clear and sharp throughout the whole zoom range.
Dual illumination system having incident and transmitted illuminators, for individual use or both at a time controlled through solid state built-in transformer 6 Volts 20 Watts for halogen Bulbs.
Packed in plywood storing cabinet with operation manual, vinyl cover etc. |
| |
|
| RSM-9A TRINOCULAR STEREO ZOOM MICROSCOPE |
| |
Stand is suitable for use in natural light or with optional external illuminators. |
| |
|
| RSM-99 TRINOCULAR STEREO ZOOM MICROSCOPE |
| |
Transmitted & Incident lights are built in the stand. The long life and low temperature fluorescent lamps are provided for continuous observation. |
| |
|
| RSM-9F TRINOCULAR STEREO ZOOM MICROSCOPE |
|
Large stage is equipped for convenience of work. A long life and low temperature 10W fluorescent lamp is provided for the built in incident light. |
| |
|
| RSM-9DF TRINOCULAR STEREO ZOOM MICROSCOPE |
|
Jewel Microscope is used to distinguish between genuine and imitation gems, to inspect surface inclusions, to judge production of origin and to inspect polishing. The Microscope is provided with transmitted and incident light system, darkfield attachment and a gem clamp. |
| |
|
|
